PV + ESS plan sets
Sealed drawing packages built to NEC, FBC, NFPA 855 and ASCE 7 — site plan, layout, one-line, riser, calculations and placards.
Florida Solar PV Design Engineering
Permit-ready plan sets, drafted in 24–48 hours.
PE-sealed photovoltaic and battery storage design for contractors across Florida. No middleman and no offshore drafting desk — you talk directly to the engineer who stamps your set.
- FL PE #91287
- NABCEP PV Design Specialist
- Electrical Contractor
- English / Español
01 / Capabilities
Everything between your site survey and an approved permit.
Residential retrofits to essential-facility commercial arrays. Every set is drawn, calculated, checked and sealed in-house.
Permit & AHJ packages
Submittal-ready packages for Miami-Dade, Broward, Monroe and the Keys. I answer reviewer comments and revise until the permit is approved.
Utility interconnection
FPL, Keys and municipal applications — load calculations, main-bus derates, meter and main upgrades.
Battery storage
Tesla Powerwall, Enphase, EP Cube and FranklinWH. Retrofits and new builds with UL 9540/9540A clearances and placards.
Structural coordination
Carports and canopies, uplift tables, Miami-Dade NOAs and mounting details for 140 mph-plus wind zones.
Owner’s engineer reviews
Third-party code-compliance and QA review of someone else’s set before it costs you a rejection.
02 / Selected work
Drawings that reviewers can follow and crews can build.
Case study — Municipal / essential facility
Orlando Fire Station 6
A 142 kW rooftop array on an active fire station — Risk Category IV, designed for 140 mph winds over a TPO roof, with four SolarEdge inverters and fire-rated penetrations detailed through the apparatus bay.
| DC system size | 142.27 kW |
|---|---|
| AC system size | 112.9 kW |
| Modules | 347 × 410 W |
| Design wind speed | 140 mph, Exposure C |
| Risk category | IV — essential facility |
| AHJ | City of Orlando |
Residential
Standing-seam metal roof array
Full-slope all-black array on a Miami-Dade residence, clamped to standing-seam without a single roof penetration.
Drawing
Residential microinverter riser
Seven circuits of Hoymiles microinverters into a 200 A combiner, surge protection and a line-side tap at the existing service.
Drawing
Multi-roof estate isometric
Twenty-three separate module rows across a complex roof, each row tagged with module and mount counts for the install crew.
03 / The engineer
I started on the roof. It shows in the drawings.
I’m Eduardo Rodriguez, a Florida Professional Engineer, Electrical Contractor and NABCEP PV Design Specialist.
I began as an installer, moved into CAD design, and today I engineer residential and commercial PV and battery systems across Florida. Over the past decade I’ve delivered more than 4,000 permitted projects — from custom off-grid systems to public facilities including the University of Miami and Pinecrest Town Hall.
Because I’ve installed what I now draw, my sets are built to be read on a roof, not just filed at a counter.
04 / Coverage
Ten years of pins on the same map.
Every marker is a permitted installation. The density in Miami-Dade and Broward is why local reviewers rarely surprise me.
Authorities having jurisdiction
Miami-Dade
Broward
Monroe / Keys
Palm Beach
City of Orlando
FPL
FKEC
Municipal utilities
Equipment experience
Tesla Powerwall
Enphase
SolarEdge
EP Cube
FranklinWH
Hoymiles
05 / How it works
Four steps, no chasing.
STEP 01
Share the basics
Address, scope, equipment list and survey photos. That is usually enough for me to scope the job accurately.
STEP 02
Quote and timeline
A fixed proposal with a clear schedule. Draft typically lands within 24 to 48 hours.
Fixed price — no hourly surprisesSTEP 03
Review and refine
You mark up the draft, I turn the edits fast. Direct phone access to me, not to a project coordinator.
STEP 04
Seal and submit
PE-sealed, permit-ready PDF, wet stamp if your AHJ needs one. I handle reviewer comments until the permit is approved.
Revisions until approvalSend me the address and the equipment list.
I’ll come back with a fixed price and a date. Most drafts are on your screen within two business days.
